Your tufting gun is a mechanical tool. And like any mechanical tool, it needs regular care to keep running at its best.
The good news: tufting gun maintenance is simple, quick, and takes less than five minutes. The bad news: most beginners skip it entirely — and then wonder why their gun starts jamming, skipping stitches, or making grinding noises halfway through a project.
This guide shows you exactly what to do and how often to do it.
⚡ Quick Answer
- Oil your tufting gun every 2–3 hours of use — or after every session
- Use sewing machine oil — lightweight, clear, and safe for the mechanism
- Apply 2–3 drops to the needle shaft and moving parts around the blade
- Never use WD-40 — it's a degreaser, not a lubricant, and will damage the mechanism
- A well-oiled gun feeds yarn smoothly, cuts cleanly, and lasts significantly longer
- Takes less than 2 minutes — no excuse to skip it
Why Oiling Matters
A tufting gun works at high speed — the needle is punching through fabric hundreds of times per minute. All that movement creates friction, and friction without lubrication causes wear.
An under-oiled gun will:
- Start to feel stiff or sluggish
- Skip stitches inconsistently
- Produce uneven pile height
- Jam mid-session
- Wear out faster than it should
An oiled gun, by contrast, feels smooth and responsive from the first stitch to the last.
What Oil to Use
Use sewing machine oil. It's lightweight, clear, non-staining, and designed for exactly this kind of high-speed mechanical use.
You can find it in most craft or sewing shops, or online for a few pounds a bottle. A small bottle will last months.
What NOT to Use
| Product | Why to Avoid |
|---|---|
| WD-40 | Degreaser, not lubricant — strips existing oil and damages parts |
| Cooking oil | Too thick, goes rancid, attracts dust |
| 3-in-1 oil | Too heavy for fine mechanisms |
| Vaseline or grease | Attracts fluff and yarn fibres |
How to Oil Your Tufting Gun: Step by Step
Step 1: Turn the Gun Off
Always oil with the gun switched off and unplugged. Never oil a running machine.
Step 2: Locate the Needle Shaft
The needle shaft is the vertical rod that the needle sits on — it moves up and down rapidly as the gun operates. This is the primary lubrication point.
On the AK-V, the needle shaft is visible at the top of the gun head, just above the needle itself.
Step 3: Apply 2–3 Drops of Oil
Using the dropper or nozzle on your oil bottle, apply 2–3 drops directly to the needle shaft. You want the oil to work its way into the moving joint — not just sit on the surface.
Don't overdo it. Too much oil attracts yarn fibres and creates a sticky residue that causes more problems than it solves.
Step 4: Oil the Blade Mechanism (Cut Pile)
If you're using your gun in cut pile mode, the blade also needs attention. Apply 1–2 drops to the blade joint — the point where the blade connects to the mechanism.
Work the gun briefly by hand (with it unplugged) to distribute the oil through the joint.
Step 5: Run the Gun Briefly on Scrap Fabric
Before returning to your project, run the gun for 10–15 seconds on a piece of scrap tufting cloth. This distributes the oil through the mechanism and removes any excess that might transfer to your yarn.
How Often Should You Oil?
| Usage | Frequency |
|---|---|
| Light use (occasional sessions) | Once per session |
| Regular use (2–3 sessions/week) | Every 2–3 hours of active tufting |
| Heavy use (daily/studio use) | Every 1–2 hours |
How to Clean Your Tufting Gun
Oiling is the main maintenance task, but occasional cleaning keeps things running even better.
After Every Session
- Remove any visible yarn fibres from around the needle and blade area using tweezers or a soft brush
- Wipe down the exterior of the gun head with a dry cloth
Monthly (or When Performance Dips)
- Use a soft brush (an old toothbrush works well) to clear fibres from the mechanism
- Check the needle for bending or blunting — a bent needle causes skipped stitches
- Check blade sharpness — a dull blade produces ragged cut pile
Signs Your Gun Needs Maintenance
| Symptom | Likely Cause | Fix |
|---|---|---|
| Skipping stitches | Under-oiled needle shaft | Oil the needle shaft |
| Sluggish or stiff movement | Dried-out mechanism | Oil all moving parts |
| Grinding or squeaking | Metal-on-metal friction | Oil immediately |
| Uneven pile height | Blade or needle issue | Check needle, oil blade joint |
| Yarn jamming frequently | Fibre build-up in mechanism | Clean + oil |
| Blade not cutting cleanly | Dull blade | Replace or service blade |
Shop sewing machine oil, replacement needles, and everything else you need at UK Tufting.
Oil it. Clean it. Keep tufting. 🧵
Having problems despite regular maintenance? Read our tufting gun troubleshooting guide for fixes to the most common issues.
